- Overview
- Product Description
Basic Info.
Model NO.
HQC23-80/1000/260-Y02
Charge Method
Quick Charge
Rated Power
80kw
Input Voltage
AC380V±10%
Protection Level
IP55
Operation Temperature
-40°c~+60°c
Gun Cable Length
Car:4.5m Bus:6m
Communications Protocol
Ocpp1.6j
Connectivity
Ethernet/WiFi/4G
Cooling
Forced Air Cooling
LED
Three Color Indicator Light
Over/Under Voltage Protection
Yes
Over Temperature Protection
Yes
Surge Protection
Yes
Emergency Stop Button
Yes
Output Voltage
200-1000V DC
Charging Point
2*CCS2
Transport Package
Safety Wooden Box Packaging
Specification
750mm*1688mm*320mm
Trademark
HARDHITTER or Customized
Origin
Shandong, China
HS Code
8504409999
Production Capacity
3000 Pieces Per Year
Packaging & Delivery
Package Size
130.00cm * 60.00cm * 190.00cm
Package Gross Weight
260.000kg
Lead Time
20 days (1 - 1 Pieces)
To be negotiated ( > 1 Pieces)
To be negotiated ( > 1 Pieces)
Product Description
Product Parameters
| Rated Power | 80kW |
| Input Voltage | AC380V±10% |
| Output Voltage | 200~1000V |
| Charging Interface | GB/T20234.1-2015 CCS1, CCS2, CHAdeMO |
| Start Mode | Swipe Card, Scan Code, Plug and Charge, Platform remote start, button Start |
| Protection Level | IP55 |
| Operation Temperature | -40°C~+60°C |
| Altitude | ≤2000m |
| Dimensions | Wall mounted:540*200*740mm Floor mounted:540*200*1400mm |
| Weight | 60kg |
| Gun Cable Length | Car:4.5m Bus:6m |
| Cooling Method | Air Cooling |
| Communication Interface | Ethernet/4G |
| Wiring Method | Bottom Incoming |
| Interface | LED+digital tube display |
| Start Mode | Swipe Card, Scan Code, Plug and Charge, Platform remote start |
Product Features
--Suitable for destination charging scenarios, including residential areas, workplaces, or shopping malls, etc
--Adopting high-efficiency dustproof mesh, it can effectively filter dust, and the protection level can reach IP55. The power module adopts a fully glue-pouring process, with high protection level, high system reliability, and long system life;
--The system has a small volume and is easy to install and connect;
--Support multiple charging startup methods such as scanning code charging, swiping card charging, plug and play charging, remote start charging, timed charging, etc.
--Adopting high-efficiency dustproof mesh, it can effectively filter dust, and the protection level can reach IP55. The power module adopts a fully glue-pouring process, with high protection level, high system reliability, and long system life;
--The system has a small volume and is easy to install and connect;
--Support multiple charging startup methods such as scanning code charging, swiping card charging, plug and play charging, remote start charging, timed charging, etc.
Company Profiles
Q&A - Q: How about your Lead time?
A: Generally, it will takes 15 to 25 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. - Q: Does your products have quality certification?
A: We have a very strict quality controlling system which promises the goods we produced are always of the best quality. Our EV charging products passes with CE&TUV certifications. - Q: How long is the warranty?
A: The warranty of our products is 12 months upon the receipt of your shipment under normal circumstances. - Q: What is your guarantee of after-sale service?
A: In response to every single after-sale request within the warranty, we will appoint a one-on-one technician for timely online aid. - Q: Can you provide customized service?
A: Yes. We have been getting involved with the OEM and ODM projects since 2012. So that we can provide professional customized service for our clients. - Q: What is your term of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance. - Q: Can the EV charger charge all Electric Vehicle on the road?
A: Yes, all models of our EV Charger work with all Electric Vehicles. Tesla vehicles need the use of a J1772 to Tesla adapter to work with our EV chargers. - Q: Does the EV Charger need any APPs or internet?
A: Some models are set be to standalone type which use RFID card to start or plug and play mode . Some models are Wi-Fi connected and can work with App and any OCPP 1.6j application. Details please feel free to ask.
