Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger

Get the Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger from our factory. Fast, efficient charging for electric vehicles. Buy now!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
NCAB170701
Input Voltage Range
220V(1 Phase)
Output Current
16A / 32A Option
Warranty
12 Months
Application
AC Home Commercial EV Charging
Color
Black
Transport Package
1PCS/Carton
Specification
40CM*24CM*12CM
Origin
Made in China
HS Code
8504409999
Production Capacity
1000pieces/Month

Product Description

Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger
Product Description

* 4.3 Inch LCD Display: LCD screen can display the real-time charging status, including time, voltage, current, power and temperature.

*All-round protection: Include voltage protection, current protection, leakage protection, temperature protection, lightning protection and other protective measures to ensure the safety.

*IP55, Strong and Durable: Support outdoor harsh environment, waterproof and dust-proof. Rugged shell which could resist the rolling and crash of the car.

*High intelligence: Powerful information collection, transmission and communication functions, supporting Blue tooth, Ethernet, 4G and WIFI wireless communication.

*Easy to install and use: The installation process is simple, payment is convenient and fast, supports mobile application software or IC card swiping. Fully compatible with all EV in the market.


Datasheet Model 7KW
 NCAB170701-001
11KW
NCAB 171101-001
22KW
 NCAB172201-001
Optional
Input Power Supply L+N+PE L1+L2+L3+N+PE L1+L2+L3+N+PE
Rated voltage AC 230V AC 400V AC 400V
Rated current 32A 16A 32A
Frequency 50/60HZ 50/60HZ 50/60HZ
Output Output voltage AC 240V AC 400V AC 400V
Output current 32A 16A 32A
Rated power 7KW 11KW 22 KW
User interface Cable length 5M Customized
Outer case PC9010
LED indicator Green/blue/red (blue standby; green charger connected to the vehicle, flashing -charging; red abnormal)
Emergency stop include
Start-up mode Plug-and-Play Yes
RFID Reader - Y N
Network 4G - Y N
RJ45 - Y N
Bluetooth/WiFi - Y N
Security RCD A+DC6mA
Ingress Protection IP65
Surge Protection IK10
Electrical Protection Overvoltage protection, undervoltage protection, grounding protection, lightning protection, leakage protection, flame retardant protection, overcurrent protection, intelligent temperature control protection, relay adhesion protection, input shutdown protection, vehicle specification level protection vehicle and protective personnel
Warranty 15 months
Cooling mode Natural cooling
Environment Installation Wall-mount/Pole-mount
Working Temperature -30°C~+50°C
Storage temperature -40°C~+80°C
Operating humidity 5%~95% no moisture condensation or frost
Working Height <2000M
Specifications Product Dimension 23*16*7.5cm
Package Dimension 47*24*25.5cm
Net Weight 2.5KG
Gross Weight 3.5KG
Packing list Charging pile 1Pcs
Instructions 1Pcs
Cable 1Pcs
Plug holder 1Pcs
Screw (for installation) 1Pcs
Outer packaging Carton
Other Efficiency ≥98
Insulation resistance ≥10MQ
Power of control module ≤7W
Terminal include
Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger
ABOUT US

Nancome Electric Technology Co., Ltd.  founded in 1992, is deeply rooted in the electrical industry with advanced technology and extensive experience. It is a national high-tech enterprise integrating product research, development, manufacturing, and sales. The company has independent technology research and development centers, production plants, and office facilities in Zhongpu, Wenzhou, and Guangzhou, with invested production bases and strong cooperative relationships. Over 30 years of development, the product range includes high and low voltage complete switchgear, communication electrical group equipment, smart power equipment, intelligent charging station equipment, compact busbar trunking, security intelligent control equipment, intelligent switches, sockets, and lighting. The company has consistently emphasized research and investment in technological innovation, acquiring a total of 36 patents, including 5 utility model invention patents, which have been widely applied to product innovation, garnering broad user recognition. Additionally, the company has formed a comprehensive electrical intelligent solution structure with design, development, production, and service, and is committed to strict quality inspection and attentive customer service, always ready to discuss customer needs to ensure satisfaction. Furthermore, we have obtained ISO 9001 and 3C, CE certificates, and established long-term business cooperation with world-renowned brands such as ABB, and Siemens, all part of the Fortune 500 companies.

Nancome Electric Charging Pile Division: The company has invested in Wenzhou, Zhejiang, to establish an integrated circuit research and development production base for charging pile and an assembly production base for AC charging piles. The company has reached a long-term collaborative research and development and commission production agreement with a DC charging pile manufacturer in Guangzhou. In 2022, a sales subsidiary,Xiamen Newcom Electrical Co.Ltd., was established in Xiamen. Xiamen, known for its unique economic status, boasts a favorable business environment. Xiamen Port is a major coastal port in China, a Class I port for foreign trade, and one of the main export ports in Fujian Province.


Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger
Frequently Asked Questions

Q: Are you a factory or a trading company?
A: We are a manufacturer, welcome to visit our factory at any time!

Q: What can you buy from us?
A: We mainly offer a wallbox/Portable AC EV charger with an output rating from 3.5kw-44kw and an integrated floor-mounted fast DC Charging station with an output rating from 30kw-480kw. Mobile chargers with energy storage batteries from 3.5kwh-161kwh, and Solar System products.

Q: Can you make our design and put our logo on the products?
A: Yes, we can make your design and put your logo on the products.

Q. Can I customize the box and packing way?
A: We can provide related services under the condition of meeting the MOQ.

Q: When can I get the price?
A: Usually we quote within 24 hours after we get your inquiry.

Q: What are your payment terms?
A: T/T 30% as deposit, 70% paid off before delivery. We will show you the photos of the products and packages before you pay the balance.

Q: What are your terms of trade?
A: EXW,  CFR, CIF, DAP, DDU, DDP.

Q: How about your delivery time?
A: Generally, it will take 7 to 35 days after receiving your advance payment. The specific delivery time depends on the item and quantity of your order.

Q: Do you test all your goods before delivery?
A: Yes, we will do a final inspection of the goods before delivery.

 Q: How do you give me your goods?
A: By air, shipping by sea, truck by DHL, TNT, UPS, FEDEX. Choose the best shipment method according to the actual situation.

Q: Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.

Q: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q: What payment methods do you accept?
A: We accept all payment methods including PayPal, T/T, Credit Card, Alibaba Assurance, Western Union, and Bank Transfer. Please contact us for more details. But if you have different requirements, we may discuss them together.

Q: What is the warranty?
A: We provide two years warranty for the whole machine and bear the transportation cost of hardware replacement in case of failure. After the warranty period. if there is a problem with spare parts, we can purchase spare parts on your behalf if you bear the cost of spare parts and transportation costs. Our software has a lifetime warranty, and our technical team can provide remote video guidance support.

Q. Does the product meet the local customs clearance standards?
A: Our products have been sold in large quantities all over the world, and all products have passed the relevant certifications recognized by the local government. In addition, we provide standardized product information and packaging to ensure full compliance with local customs clearance requirements.
If you have special requirements for customs clearance in your local area, please contact us before placing an order, we can provide timely and effective assistance.


Nancome New Energy AC Wall Box Mounted Mode2 Smart EV Mobile Charger
